Cixi Wan Hai Electronics Co., Ltd.

Material and plating
Pin header	Brass,Tin plated
Plastic	PA66，UL94V-0

Electrical Performance
Reference Standard	UL	IEC
Rated voltage	300V	250V
Rated current	8A	10A
Contact resistance	20mΩ
Insulation resistance	500MΩ/DC500V
Withstand Voltage	AC2000V/1Min

Mechanical
Temperature range	-40°C~+105°C
Instantaneous temperature	+250°C 5秒
replique montre suisse
Size	borse firmate imitazioni perfette
Pitch	3.5mm(.138"),3.81mm(.150")
Poles	2P-24P
