Mini Din connector applys to a variety of audio and video interface. Because of them, the wire and board can be connected. According to different requirements, 3 pin to 8 pin can be selected. Products are designed in accordance with CE, ROHS, REACH standard
MINI-DIN 3-9Pin Female & Male
Model：HY1148-01
Voltage rating：/
Current rating：/
Positions：3-9
MINI-DIN 803 Type
Model：HY1148-02
Voltage rating：30V
Current rating：1.0A
Positions：4-8
MINI-DIN 824 Type
Model：HY1148-03
Voltage rating：30V
Current rating：1.0A
Positions：6
MINI-DIN 901Type
Model：HY1148-04
Voltage rating：30V
Current rating：1.0A
Positions：4-8
MINI-DIN 810 Type With
Flange
Model：HY1148-05
Voltage rating：30V
Current rating：1.0A
Positions：4-8
MINI-DIN 422 Type
Model：HY1148-06
Voltage rating：30V
Current rating：1.0A
Positions：4
MINI-DIN 801 Type
Model：HY1148-07
Voltage rating：30V
Current rating：1.0A
Positions：4
MINI-DIN 804 Type
Model：HY1148-08
Voltage rating：30V
Current rating：1.0A
Positions：3-8
MINI DIN Male With Hood Type
Model：HY1148-09
Voltage rating：/
Current rating：/
Positions：3-8
