Cixi Wan Hai Electronics Co., Ltd.

Material
Screw	M3.0，Zinc plated
Clamp	Cladded copper strips Zinc plated
Plastic	PA66，UL94V-0

Electrical
Standard	UL	IEC
Rated voltage	300V	450V
Rated current	26A	41A
Wire range	20-10AWG	2.5mm2
Internal Cylindrical Gage	/
Stripping Length	6-7mm
Rated Surge Voltage	2.5KV

Mechanical
Temperature range	-40°C~+105°C
Tightening Torque	0.5Nm(4.0Lb-in)

Size
Pitch	10. 0mm(.394")
Poles	2P-12P
