Cixi Wan Hai Electronics Co., Ltd.

Material
Contacts	Copper Alloy
Plating	According to order request
Plastic	PBT With Glass Fiber Filled，30% G.F

Electrical
Standard	/	/
Rated voltage	/	/
Rated current	/	/
Wire range	/	/
Contact resistance	20mΩ Max.(intial).
Insulation resistance	1000MΩ Min
Withstand Voltage	AC 500V/Min

Mechanical
Temperature range	-40°C~+105°C
Max.Torque	/
Strip length	/

Size
Pitch	2.0mm
poles	10-68
