Cixi Wan Hai Electronics Co., Ltd.

Material
Insulator	PBT with glass fiber thermoplastic(UL 94V-0)
Contact	Copper alloy
Color	see ordering information
Contact Plated	see ordering information

Electrical
Standard	/	/
Rated voltage	3A	/
Rated current	/	/
Wire range	/	/
Contact resistance	30mΩ max.
Insulation resistance	1000MΩ/DC500V
Withstand Voltage	AC500V/1Min

Mechanical
Temperature range	-40°C~+105°C
Max.Torque	/
Strip length	/

Size
Pitch	2.16mm
Poles	14/24/36/50
