Cixi Wan Hai Electronics Co., Ltd.

Material
Screw	M2.5，Zinc plated
Clamp	Cladded copper strips Zinc plated
Plastic	PA66，UL94V-0

Electrical
Standard	UL	IEC
Rated voltage	300V	450V
Rated current	17.5A	24A
Wire range	20-14AWG	1.5mm2
Internal Cylindrical Gage	/
Stripping Length	6-7mm
Rated Surge Voltage	2.5KV

Mechanical
Temperature range	-40°C~+105°C
Tightening Torque	0.4Nm(3.5Lb-in)

Size
Pitch	8. 0mm(.300")
Poles	2P-12P
